After 10 years of production the ADSII has evolved into a highly advanced digitally controlled anesthesia system. The latest ADSII offers the same sturdy construction as previous models but now offers the latest advancements in anesthesia delivery and patient ventilation. The ADSII provides extremly accurate fresh gas delivery via electronic flowmeters. The ADSII ventilator has been upgraded with a larger 10.1 inch color screen with more ventilation modes and a user friendly software interface. Many advanced patient monitoring options are available with the ADSII particularly: Auto ID Anesthetic Agent Measurement, EtCO2, 12 lead ECG, Invasive Blood Pressures, and Cardiac Output. Further Specifications are listed below. Please contact sales@site_99d86bc1-9f52-4353-b1cf-4e5e15333b21 for further information.
Ventilator
- mode VCV，PCV，SIMV+VCV+PSV，SIMV+PCV+PSV，Manual, Standby
- Tidal volume(VT) 20～1500 mL
- Frequency (f) 1 ～ 60 bpm
- I:E 3:1～1:6（Increment：0.5）
- Ti 0.1～10 s（Increment：0.1 s）
- Inspiratory pause (Tp) OFF，5%～50%
- E-PEEP Integrated electronic PEEP OFF，4～30 cmH2O
- Flow trigger (FTRIG) 1～15 L/min
- Pressure control 5～70 cmH2O
- Pressure support
- Pressure Limit
- 5～60 cmH2O
- PEEP+5～PEEP+70 cmH2O
Pneumatics
- Gas supply Pipeline：O2, N2O and Air；Optional Yokes: 1x O2 ;1x N2O;
- Pressure gauge Mechanical
- Flowmeter electronic flow meters for O2, N2O and air； O2 and N2O linkage and N2O cutoff function
- Bellows volume Adult，0～1500 mL，pediatric(optional)，0～300 mL
- APL valve 2～70 cmH2O
- CO2 Canister Volume
- By-pass
- 1.5 L（1.35 Kg）
- Automatic; change soda lime during operation.
- bag/vent switch switch for manual ventilation and mechanical ventilation
Monitoring
- C, R, VTE, VTI, MV, MVspn, f, fspn, I:E, Ppeak, Pmean， Pplat， Pmini
- Waveforms; P-T, F-T, V-T, Loop V-P, F-V, F-P
- Optional: SpO2, EtCo2, NIPB, IPB, CO, ECG (3,5,or 12 Lead), Agent ID
Please contact sales@site_99d86bc1-9f52-4353-b1cf-4e5e15333b21 for distributor pricing
